EGLOBAL Top Gaming Computer Intel Xeon E-2176M 12M Cache 14nm Nuc Fan Mini PC Win10 Pro HDMI AC WiFi BT are designed for unique, office applications that require compact size, durability, high reliability, and universal performance. These characteristics make these Fan Small PC and Mini Desktop PC ideal for applications like manufacturing, industrial automation, medical, semiconductor, food processing, machine control, and other scenarios in which desktops and notebooks are not feasible, yet high processing performance is needed.

Main advantages of EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC:
1. Small size: all EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC smaller than A4 paper, some of them only 3.5 inch size, just like the HDD sized using it traditional fat computers. Most of those small sized mini pc can be mounted to the backside of monitor, and takes almost no space of your desk, make your desk more clear and smart.
2. Durability: all those EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC are highly intergrated, fan design makes it runs silent and no need extra maintenance like normal fat computers. And most of them using aluminium alloy computer case, very durable.
3. Low power: all the EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC using  12V or 19V power supply, most of them power consumption from 15W to 30W, compare to 150W traditional pc's consumption, it helps saving more than 80% energy.
4. Universal performance: EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC compatible with almost all popular operating systems, such as Windows, Linux. You can use it as personal computer at home, or use it as HTPC to built your own home theater center, and also you can use it in offices, training centers, factories, internet cafe and everywhere that require computers.

What can this EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC?
Office work: Office, skype, yahoo, outlook and all other office requirement support and runs perfect;
Design work: Photoshop, CoreIDRAW, Dreamweaver, Illustrator, Flash, In-design and others
Game playing: support most online games and PC games, like Warcraft, Counter-Strike (CS), support 3D games but this is integrated graphic not independent cards, so don't play very high grade 3D games.
Entertainment: support blu ray 1080P and 4k video play, XBMC and others


EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC Features:
Fan system with cooling fan
Appropriate product design: Contracted design style, super mini body and good performance, the heat dissipation capability of stable
Strict ME tolerance control: Full experience tooling design and CNC process good gap control in final system assembly process
Support PXE, AWAL, RTC function
1*USB-C connector
Package Content: 1*Mini PC, 1*Power Adapter, 1*VESA mount, 1*Mini-DP to VGA adapter
CE, FCC, ROHS, BIS, Energy Star certification
♦  Intel Xeon E-2176M, 12M Cache, 6 Core 12 Threads, 14nm, 2.7GHz up to 4.4GHz, TDP 45W, Intel UHD Graphics P630,350MHz~1.2GHz.


EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC Specifications:

Basic Information:

CPU

Intel Core i9-8950HK/ Intel Core i7-8750H/ Intel Core i5-8300H

TDP

45W

Chipset

Intel 100 series PCH

Memory

2* SO-DDR4 SDRAM Slot, Support 4GB/8GB/16GB/32GB

Dual Channel, DDR4-2666, LPDDR3L-2133

OS

Windows 10

PXE

Yes

Audio

Azalia Codec support 2.1 channel output

High Definition Audio Controller

Network

Onboard RTL8111 PCI-E Gigabit Ethernet NIC

10/100/1000 BaseT LAN

Video

Intel® UHD Graphics 630

Input/output port

Switch

1 x Power On/Off Switch

Power

1 x 19V DC In

LED

1 x LED

USB

1 x Type-C, 4 x USB3.0

Display

1 x Mini DP, 1 x HDMI

LAN

1 x RJ45 Intel Giga LAN

Audio

1 x MIC, 1 x SPK

Others

1 x Kensington Lock

Storage

MSATA

1 x M.2 slot for M.2 NGFF 22*80 SSD, up to 2TB(Only NVME), support 6Gb/s

1 x M.2 slot for M.2 NGFF 22*80 SSD, up to 2TB(NGFF/NVME), support 6Gb/s

SATA

1 x SATA3.0 slot for 9.5mm SATA HDD or SSD, up to 3TB, support 6Gb/s

Wi-Fi

Module

1 x M.2 NGFF 2230 slot for Wi-Fi module

Antenna

2 x inner RF cables and 2 x external antennas

Power and Working Environment

Input

DC100-240V AC/50-60Hz

Output

DC +12V~+19V,recommend 19v/3-5A

Operating Temperature

0/70 Centigrade(32F~140F)

Storage Temperature

-20/+80 Centigrade

Relative Humidity

0%~90% (non-condensing)

Product Dimension & Details

Size

134*144*64mm

Weight

Net 1.1kg, Gross 3.0kg

Shell

Black color aluminum alloy(any customized color for bulk order)

Mounting

4 Mounting holes on case

Cooling Mode

Cooling Fan

Functions

Support PXE, AWAL, RTC function

Package Content

Standard

1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag

Optional

Wi-Fi antennas, 1xHDMI cable, 1xUser Manual, 1x Mini-DP to VGA adapter
