EGLOBAL Top Gaming Computer Intel Xeon E-2176M 12M Cache 14nm Nuc Fan Mini PC Win10 Pro HDMI AC WiFi BT are designed for unique, office applications that require compact size, durability, high reliability, and universal performance. These characteristics make these Fan Small PC and Mini Desktop PC ideal for applications like manufacturing, industrial automation, medical, semiconductor, food processing, machine control, and other scenarios in which desktops and notebooks are not feasible, yet high processing performance is needed.

Main advantages of EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC:
1. Small size: all EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC smaller than A4 paper, some of them only 3.5-inch size, just like the HDD sized using it traditional fat computers. Most of those small sized mini pc can be mounted to the backside of the monitor and takes almost no space of your desk, make your desk more clear and smart.
2. Durability: all those EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC are highly integrated, fan design makes it runs silent and no need extra maintenance like normal fat computers. And most of them using aluminum alloy computer case, very durable.
3. Low power: all the EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC using  12V or 19V power supply, most of them power consumption from 15W to 30W, compare to 150W traditional PC's consumption, it helps saving more than 80% energy.
4. Universal performance: EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC compatible with almost all popular operating systems, such as Windows, Linux. You can use it as a personal computer at home, or use it as HTPC to built your own home theater center, and also you can use it in offices, training centers, factories, internet cafes and everywhere that require computers.

What can this EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC?
Office work: Office, skype, yahoo, outlook, and all other office requirement support and runs perfect;
Design work: Photoshop, CorelDRAW, Dreamweaver, Illustrator, Flash, In-design and others
Game playing: support most online games and PC games, like Warcraft, Counter-Strike (CS), support 3D games but this is integrated graphic not independent cards, so don't play very high grade 3D games.
Entertainment: support blu ray 1080P and 4k video play, XBMC, and others


EGLOBAL Top Gaming Computer Intel NUC Fan Mini PC Specifications:

Basic Information:

CPU

Intel X-eon 2176M

CPU install Method

BGA1440

TDP

45W

Level 2 Cache

Depend on CPU

Motherboard

136 x 126mm customized size

Code Name

Intel Coffee Lake

Chipset

Intel 300 series PCH

Memory

2 x SO-DIMM Slot, up to 64GB DDR4

Dual Channel, DDR4-2800MHz, DDR4-2666MHz, DDR4-2400MHz, DDR4-2133MHz

ECC Memory Support: YES

OS

Windows 10

Audio

Azalia Codec support 2.1 channel output

High Definition Audio Controller

Network

1)10/100/1000Mbps Ethernet

2) Intel® Ethernet Connection I219-V

3) Intel® Ethernet Connection I211-AT

Video

Intel® UHD Graphics 630

Input/output port

Switch

1 x Power On/Off Switch

Power

1 x 19V DC In

LED

1 x LED

USB

4 x USB3.0, 2X USB2.0

Type-C

1 x Type-C USB3.1

Display

1 x DP1.2 out(support 4k@60Hz), 1 x HDMI2.0 out(support 4K@60Hz)

LAN

2 x RJ45 Intel Giga LAN

Audio

1 x Audio(MIC&SPK)

Others

1 x Kensington Lock hole

Storage



MSATA

1 x M.2 slot for M.2 NGFF 22*80(Key M), up to 2TB(Only NVME PCIe3.0x4), support 6Gb/s

1 x M.2 slot for M.2 NGFF 22*80(Key M), up to 2TB(NVME/SATA), support 6Gb/s

SATA

1 x SATA3.0 slot for 9.5mm SATA HDD or SSD, up to 3TB, support 6Gb/s

Wi-Fi



Module

1 x M.2 NGFF 2230(Key E) slot for Wi-Fi module(2.4G or 5G Wi-Fi B/G/N/AC or Bluetooth)

Antenna

2 x inner RF cables and 2 x external antennas

Power and Working Environment

Input

DC100-240V AC/50-60Hz

Output

DC +12V~+19V, recommend 19V 90W

Operating Temperature

0/70 Centigrade

Storage Temperature

-20/+80 Centigrade

Relative Humidity

0%~90% (non-condensing)

Product Dimension & Details

Size

134*144*64mm

Weight

Net 1.05kg, Gross 3.0kg

Shell

Brushed Black color aluminum alloy

Cooling Mode

Cooling Fan

Functions

1) Intel® Optane Memory Supported: Yes

2) Intel® Virtualization Technology (VT-x): Yes

3) Wake on Lan : Yes

4) Wake on AC : Yes

5) PXE Boot: Yes.

Package Content



Standard

1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag, 1xVESA mount

Optional

Wi-Fi antennas, 1xHDMI cable, 1xUser Manual
